LP-4300 Precision Low Profile Scale


The Eagle Microsystems precision LP-4300  platform scales are designed for applications requiring accuracies of 0.1% or better. The low profile LP-4300 scale can be used with liquids or dry powders, because accuracy is unaffected and independent of container positioning. The LP-4300 scale uses a rugged 4 load cell platform design with a 200% overload capacity. Thanks to the LP-4300 platform scales design, it is incredibly easy to install and maintain. Leveling the LP-4300 is performed from the top of the scale deck on, on site, with just a simple screwdriver. The weighing surface is protected by a textured Polane finish. The load cells, leveling feet, and hardware are stainless steel to ensure longevitiy in harsh environments. Use with Eagle Microsystems’ single, dual, or multiple channel display/transmitters.

System Features

  • Four standard sizes plus custom versions available
  • Low 3” height
  • Four (4) Stainless steel environmentally sealed load cells
  • Factory calibrated
  • Stainless steel hardware
  • Capacities from 500 to 20,000 lbs
  • Stainless steel deck version available
  • 2-year base warranty

Download a PDF Data Sheet
Download LP4300 Operators Manual
Download LP4300 Hi Cap Specifications
Download LP4300 Lo Cap Specifications
